Name: High Speed Stud and Track Roll Forming Machine With PLC Control System
Brand: Friendship
Price: 1 USD

Place of Origin : China

Brand Name : Friendship

Certification : ISO

MOQ : One set

Price : as per client requirements

Packaging Details : plastic film or plywood box

Delivery Time : 60days

Payment Terms : T/T or LC

Supply Ability : 100 sets per months

processing material : processing material

roller driven : decelerating motor+chain transmission

cutting mode : hydraulic cutting device

control style : PLC

roller material : Cr12

SPEED : 15-20m/min

Contact Now

High Speed Stud and Track Roll Forming Machine

With PLC Control System

Technical parameter of stud roll forming machine:

No.	item	speciafication
1.	processing material	GI strip coils
2.	processing thickness	0.3-0.6mm
3.	productivity	15-20m/min
4.	roller material	Cr12
5.	number of roller stations	13
6.	roller driven	decelerating motor+chain transmission
7.	diameter of shaft	Φ50mm
8.	length measurement	encoder
9.	cutting mode	hydraulic cutting device
10.	operation mode	button+touch screen
11.	control style	PLC
12.	driven system	single
13.	total power	8kw
14.	voltage	380v 50hz or as your requirements

Working flow:

Passive decoiler----feeding---rollforming----straightening----hydraulic cutting----run out table

High Speed Stud and Track Roll Forming Machine With PLC Control System
